In this step, you will add the relevant MariaDB package repositories to each of your three servers so that you will be able to install the right version of MariaDB used in this tutorial. Once the repositories are updated on all three servers, you will be ready to install MariaDB.
One thing to note about MariaDB is that it originated as a drop-in replacement for MySQL, so in many configuration files and startup scripts, you’ll see mysql rather than Mariadb. In many cases, these are interchangeable. For consistency’s sake, we will use MariaDB in this guide where either could work.
In this tutorial, you will use MariaDB version 10.4. Since this version isn’t included in the default CentOS repositories, you’ll start by adding the external CentOS repository maintained by the MariaDB project to all three of your servers.
Note: MariaDB is a well-respected provider, but not all external repositories are reliable. Be sure to install only from trusted sources.
First, you’ll add the MariaDB repository key by creating a repository file with a text editor. This tutorial will use vi:
sudo vi /etc/yum.repos.d/mariadb.repo
Next, add the following contents to the file by pressing i to enter insert mode, then adding the following:
/etc/yum.repos.d/mariadb.repo
[mariadb]
name = MariaDB
baseurl = http://yum.mariadb.org/10.4/centos7-amd64
gpgkey=https://yum.mariadb.org/RPM-GPG-KEY-MariaDB
gpgcheck=1
Press the esc key to return to normal mode, then type :wq to save and exit the file. If you would like to learn more about the text editor vi and its predecessor vim, take a look at our tutorial on Installing and Using the Vim Text Editor on a Cloud Server.
Once you have created the repository file, enable it with the following command:
sudo yum makecache --disablerepo='*' --enablerepo='mariadb'
The makecache command caches the repository metadata so that the package manager can install MariaDB, with --disablerepo and --enablerepo targeting the command to the mariadb repo file that you just created.
You will receive the following output:
OutputLoaded plugins: fastestmirror
Loading mirror speeds from cached hostfile
mariadb | 2.9 kB 00:00:00
(1/3): mariadb/primary_db | 43 kB 00:00:00
(2/3): mariadb/other_db | 8.3 kB 00:00:00
(3/3): mariadb/filelists_db | 238 kB 00:00:00
Metadata Cache Created
Once you have enabled the repository on your first server, repeat for your second and third servers.
Now that you have successfully added the package repository on all three of your servers, you’re ready to install MariaDB in the next section.
In this step, you will install the actual MariaDB packages on your three servers.
Beginning with version 10.1, the MariaDB Server and MariaDB Galera Server packages are combined, so installing MariaDB-server will automatically install Galera and several dependencies:
sudo yum install MariaDB-server MariaDB-client
You will be asked to confirm whether you would like to proceed with the installation. Enter yes to continue with the installation. You will then be prompted to accept the GPG key that authenticates the MariaDB package. Enter yes again.
When the installation is complete, start the mariadb service by running:
sudo systemctl start mariadb
Enable the mariadb service to be automatically started on boot by executing:
sudo systemctl enable mariadb
From MariaDB version 10.4 onwards, the root MariaDB user does not have a password by default. To set a password for the root user, start by logging into MariaDB:
sudo mysql -uroot
Once you’re inside the MariaDB shell, change the password by executing the following statement, replacing your_password with your desired password:
set password = password("your_password");
You will see the following output indicating that the password was set correctly:
OutputQuery OK, 0 rows affected (0.001 sec)
Exit the MariaDB shell by running the following command:
quit;
If you would like to learn more about SQL or need a quick refresher, check out our MySQL tutorial.
You now have all of the pieces necessary to begin configuring the cluster, but since you’ll be relying on rsync and policycoreutils-python in later steps to sync the servers and to control Security-Enhanced Linux (SELinux), make sure they’re installed before moving on:
sudo yum install rsync policycoreutils-python
This will confirm that the newest versions of rsync and policycoreutils-python is already available or will prompt you to upgrade or install it.
Once you have completed these steps, repeat them for your other two servers.
Now that you have installed MariaDB successfully on each of the three servers, you can proceed to the configuration step in the next section.
In this step you will configure your first Galera node. Each node in the cluster needs to have a nearly identical configuration. Because of this, you will do all of the configuration on your first machine, and then copy it to the other nodes.
By default, MariaDB is configured to check the /etc/mysql/conf.d directory to get additional configuration settings from files ending in .cnf. Create a file in this directory with all of your cluster-specific directives:
sudo vi /etc/my.cnf.d/galera.cnf
Add the following configuration into the file. The configuration specifies different cluster options, details about the current server and the other servers in the cluster, and replication-related settings. Note that the IP addresses in the configuration are the private addresses of your respective servers; replace the highlighted lines with the appropriate IP addresses:
/etc/my.cnf.d/galera.cnf
[mysqld]
binlog_format=ROW
default-storage-engine=innodb
innodb_autoinc_lock_mode=2
bind-address=0.0.0.0
# Galera Provider Configuration
wsrep_on=ON
wsrep_provider=/usr/lib64/galera-4/libgalera_smm.so
# Galera Cluster Configuration
wsrep_cluster_name="test_cluster"
wsrep_cluster_address="gcomm://First_Node_IP,Second_Node_IP,Third_Node_IP"
# Galera Synchronization Configuration
wsrep_sst_method=rsync
# Galera Node Configuration
wsrep_node_address="This_Node_IP"
wsrep_node_name="This_Node_Name"
The first section modifies or re-asserts MariaDB/MySQL settings that will allow the cluster to function correctly. For example, Galera won’t work with MyISAM or similar non-transactional storage engines, and mysqld must not be bound to the IP address for localhost.
The “Galera Provider Configuration” section configures the MariaDB components that provide a WriteSet replication API. This means Galera in your case, since Galera is a wsrep (WriteSet Replication) provider. You specify the general parameters to configure the initial replication environment. This doesn’t require any customization, but you can learn more about Galera configuration options here.
The “Galera Cluster Configuration” section defines the cluster, identifying the cluster members by IP address or resolvable domain name and creating a name for the cluster to ensure that members join the correct group. You can change the wsrep_cluster_name to something more meaningful than test_cluster or leave it as-is, but you must update wsrep_cluster_address with the private IP addresses of your three servers.
The “Galera Synchronization Configuration” section defines how the cluster will communicate and synchronize data between members. This is used only for the state transfer that happens when a node comes online. For your initial setup, you are using rsync, because it’s commonly available and does what you’ll need for now.
The “Galera Node Configuration” section clarifies the IP address and the name of the current server. This is helpful when trying to diagnose problems in logs and for referencing each server in multiple ways. The wsrep_node_address must match the address of the machine you’re on, but you can choose any name you want in order to help you identify the node in log files.
When you are satisfied with your cluster configuration file, copy the contents into your clipboard and save and close the file.
Now that you have configured your first node successfully, you can move on to configuring the remaining nodes in the next section.
In this step, you will configure the remaining two nodes. On your second node, open the configuration file:
sudo vi /etc/mysql/my.cnf.d/galera.cnf
Paste in the configuration you copied from the first node, then update the Galera Node Configuration to use the IP address or resolvable domain name for the specific node you’re setting up. Finally, update its name, which you can set to whatever helps you identify the node in your log files:
/etc/mysql/my.cnf.d/galera.cnf
. . .
# Galera Node Configuration
wsrep_node_address="This_Node_IP"
wsrep_node_name="This_Node_Name"
. . .
Save and exit the file.
Once you have completed these steps, repeat them on the third node.
With Galera configured on all of your nodes, you’re almost ready to bring up the cluster. But before you do, make sure that the appropriate ports are open in your firewall and that a SELinux policy has been created for Galera.
In this step, you will configure your firewall so that the ports required for inter-node communication are open.
On every server, check the status of the firewall you set up in the Prerequisites section by running:
sudo firewall-cmd --list-all
In this case, only SSH, DHCP, HTTP, and HTTPS traffic is allowed through:
Outputpublic
target: default
icmp-block-inversion: no
interfaces:
sources:
services: ssh dhcpv6-client http https
ports:
protocols:
masquerade: no
forward-ports:
source-ports:
icmp-blocks:
rich rules:
If you tried to start the cluster now, it would fail because the firewall would block the connections between the nodes. To solve this problem, add rules to allow MariaDB and Galera traffic through.
Galera can make use of four ports:
3306 For MariaDB client connections and State Snapshot Transfer that use the mysqldump method.
4567 For Galera Cluster replication traffic. Multicast replication uses both UDP transport and TCP on this port.
4568 For Incremental State Transfers, or IST, the process by which a missing state is received by other nodes in the cluster.
4444 For all other State Snapshot Transfers, or SST, the mechanism by which a joiner node gets its state and data from a donor node.
In this example, you’ll open all four ports while you do your setup. Once you’ve confirmed that replication is working, you’d want to close any ports you’re not actually using and restrict traffic to just servers in the cluster.
Open the ports with the following commands:
sudo firewall-cmd --permanent --zone=public --add-port=3306/tcp
sudo firewall-cmd --permanent --zone=public --add-port=4567/tcp
sudo firewall-cmd --permanent --zone=public --add-port=4568/tcp
sudo firewall-cmd --permanent --zone=public --add-port=4444/tcp
sudo firewall-cmd --permanent --zone=public --add-port=4567/udp
Using --zone=public and --add-port= here, firewall-cmd is opening up these ports to public traffic. --permanent ensures that these rules persist.
Note: Depending on what else is running on your servers you might want to restrict access right away. To learn more about how to use FirewallD, see our tutorial How To Set Up a Firewall Using FirewallD on CentOS 7.
Now, add each server to the public zone by executing the following commands, replacing the highlighted text with the respective private IP addresses of your nodes:
sudo firewall-cmd --permanent --zone=public --add-source=galera-node-1-ip/32
sudo firewall-cmd --permanent --zone=public --add-source=galera-node-2-ip/32
sudo firewall-cmd --permanent --zone=public --add-source=galera-node-3-ip/32
Reload the firewall to apply the changes:
sudo firewall-cmd --reload
After you have configured your firewall on the first node, create the same firewall settings on the second and third node.
Now that you have configured the firewalls successfully, you’re ready to create a SELinux policy in the next step.
In this section, you will create a SELinux policy that will allow all the nodes in the cluster to be able to communicate with each other and perform cluster operations.
SELinux is a Linux kernel module that improves the security of operating systems with its support for access control and mandatory access control policies. It is enabled by default on CentOS 7 and restricts the MariaDB daemon from performing many activities.
In order to create the policy, you will perform various activities on the cluster with the SELinux mode set to permissive for MySQL. You will then create a policy from the logged events and finally set the SELinux mode to enforcing once the policy is installed successfully.
First, allow access to the relevant ports by running the following commands on all three servers:
sudo semanage port -a -t mysqld_port_t -p tcp 4567
sudo semanage port -a -t mysqld_port_t -p udp 4567
sudo semanage port -a -t mysqld_port_t -p tcp 4568
sudo semanage port -a -t mysqld_port_t -p tcp 4444
Note: You may receive a ValueError when allowing access to some of these ports. This means that the SELinux status of that port has already been set, which in this case will not affect the process of this tutorial.
In these commands, you are using the SELinux management tool semanage with the -a flag to add specified ports and to ignore the database server.
Next, run the following command on all three servers, which sets the MySQL SELinux domain to permissive mode temporarily.
sudo semanage permissive -a mysqld_t
This command can take a minute to complete and will not display any output.
Next, stop the database server on all the nodes so that you will be able to bootstrap the database cluster with shared SELinux policies. To do this, run the following command on all three nodes:
sudo systemctl stop mariadb
Now, bootstrap the cluster to generate inter-node communication events that will be added to the SELinux policy. On the first node, bootstrap the cluster by executing:
sudo galera_new_cluster
Create a database and table for the specific purpose of logging SST events by running the following on the first node:
mysql -u root -p -e 'CREATE DATABASE selinux;
CREATE TABLE selinux.selinux_policy (id INT NOT NULL AUTO_INCREMENT, PRIMARY KEY(id));
INSERT INTO selinux.selinux_policy VALUES ();'
Now start the server on the second node:
sudo systemctl start mariadb
Then do the same on the third node:
sudo systemctl start mariadb
You will not see any output for the previous commands. To generate IST events, execute the following on all three servers:
mysql -u root -p -e 'INSERT INTO selinux.selinux_policy VALUES ();'
Now create and enable the SELinux policy by executing the following commands on all three servers:
sudo grep mysql /var/log/audit/audit.log | sudo audit2allow -M Galera
This first command searches for generated events in the audit.log file and pipes them to a module named Galera.pp generated by the audit2allow tool. This will result in the following output:
Output******************** IMPORTANT ***********************
To make this policy package active, execute:
semodule -i Galera.pp
Next, follow the instructions in the output and use the following command to install the generated module:
sudo semodule -i Galera.pp
Now that the policy is active, disable permissive mode for the MariaDB server:
sudo semanage permissive -d mysqld_t
Now that you have successfully created a SELinux policy and enabled it, you are ready to start the cluster in the next section.
In this step, you will start your MariaDB cluster. To begin, you need to stop the running MariaDB service so that you can bring your cluster online.
When stopping the MariaDB service, it is important to execute this action on your servers in a specific order. This shutdown sequence ensures that the first node will be able to safely bootstrap the cluster when it starts up.
First, run the following command on the third node:
sudo systemctl stop mariadb
Next, stop the service on the second node:
sudo systemctl stop mariadb
Finally, stop the service on the first node:
sudo systemctl stop mariadb
systemctl doesn’t display the outcome of all service management commands, so to be sure you succeeded, use the following command on each of your servers:
sudo systemctl status mariadb
The last line will look something like the following:
Output. . .
Apr 26 03:34:23 galera-node-01 systemd[1]: Stopped MariaDB 10.4.4 database server.
Once you’ve shut down mariadb on all of the servers, you’re ready to proceed.
To bring up the first node, you’ll need to use a special startup script. The way you’ve configured your cluster, each node that comes online tries to connect to at least one other node specified in its galera.cnf file to get its initial state. Without using the galera_new_cluster script that allows systemd to pass the --wsrep-new-cluster parameter, a normal systemctl start mariadb would fail because there are no nodes running for the first node to connect with.
sudo galera_new_cluster
This command will not display any output on successful execution. When this script succeeds, the node is registered as part of the cluster, and you can see it with the following command:
mysql -u root -p -e "SHOW STATUS LIKE 'wsrep_cluster_size'"
You will see the following output indicating that there is one node in the cluster:
Output+--------------------+-------+
| Variable_name | Value |
+--------------------+-------+
| wsrep_cluster_size | 1 |
+--------------------+-------+
On the remaining nodes, you can start mariadb normally. They will search for any member of the cluster list that is online, so when they find one, they will join the cluster.
Now you can bring up the second node. Start mariadb:
sudo systemctl start mariadb
No output will be displayed on successful execution. You will see your cluster size increase as each node comes online:
mysql -u root -p -e "SHOW STATUS LIKE 'wsrep_cluster_size'"
You will see the following output indicating that the second node has joined the cluster and that there are two nodes in total.
Output+--------------------+-------+
| Variable_name | Value |
+--------------------+-------+
| wsrep_cluster_size | 2 |
+--------------------+-------+
It’s now time to bring up the third node. Start mariadb:
sudo systemctl start mariadb
Run the following command to find the cluster size:
mysql -u root -p -e "SHOW STATUS LIKE 'wsrep_cluster_size'"
You will see the following output, which indicates that the third node has joined the cluster and that the total number of nodes in the cluster is three.
Output+--------------------+-------+
| Variable_name | Value |
+--------------------+-------+
| wsrep_cluster_size | 3 |
+--------------------+-------+
At this point, the entire cluster is online and communicating successfully. Next, you can ensure the working setup by testing replication in the next section.
You’ve gone through the steps up to this point so that your cluster can perform replication from any node to any other node, known as active-active replication. Follow the following steps to test and see if the replication is working as expected.
You’ll start by making database changes on your first node. The following commands will create a database called playground and a table inside of this database called equipment.
mysql -u root -p -e 'CREATE DATABASE playground;
CREATE TABLE playground.equipment ( id INT NOT NULL AUTO_INCREMENT, type VARCHAR(50), quant INT, color VARCHAR(25), PRIMARY KEY(id));
INSERT INTO playground.equipment (type, quant, color) VALUES ("slide", 2, "blue");'
In the previous command, the CREATE DATABASE statement creates a database named playground. The CREATE statement creates a table named equipment inside the playground database having an auto-incrementing identifier column called id and other columns. The type column, quant column, and color column are defined to store the type, quantity, and color of the equipment respectively. The INSERT statement inserts an entry of type slide, quantity 2, and color blue.
You now have one value in your table.
Next, look at the second node to verify that replication is working:
mysql -u root -p -e 'SELECT * FROM playground.equipment;'
If replication is working, the data you entered on the first node will be visible here on the second:
Output+----+-------+-------+-------+
| id | type | quant | color |
+----+-------+-------+-------+
| 1 | slide | 2 | blue |
+----+-------+-------+-------+
From this same node, you can write data to the cluster:
mysql -u root -p -e 'INSERT INTO playground.equipment (type, quant, color) VALUES ("swing", 10, "yellow");'
From the third node, you can read all of this data by querying the table again:
mysql -u root -p -e 'SELECT * FROM playground.equipment;'
You will see the following output showing the two rows:
Output +----+-------+-------+--------+
| id | type | quant | color |
+----+-------+-------+--------+
| 1 | slide | 2 | blue |
| 2 | swing | 10 | yellow |
+----+-------+-------+--------+
Again, you can add another value from this node:
mysql -u root -p -e 'INSERT INTO playground.equipment (type, quant, color) VALUES ("seesaw", 3, "green");'
Back on the first node, you can verify that your data is available everywhere:
mysql -u root -p -e 'SELECT * FROM playground.equipment;'
You will see the following output, which indicates that the rows are available on the first node.
Output +----+--------+-------+--------+
| id | type | quant | color |
+----+--------+-------+--------+
| 1 | slide | 2 | blue |
| 2 | swing | 10 | yellow |
| 3 | seesaw | 3 | green |
+----+--------+-------+--------+
You’ve verified successfully that you can write to all of the nodes and that replication is being performed properly.
At this point, you have a working three-node Galera test cluster configured. If you plan on using a Galera cluster in a production situation, it’s recommended that you begin with no fewer than five nodes.
